UniWinder

UniWinder

Winder for carpet or technical yarns.

Advantages

  • Each spindle is Independent or can be grouped.
  • With the automatic doffing of packages labor is reduced to the  absolute minimum.
  • Low maintenance cost.
  • Robust design with few moving parts and integrated maintenance interface allow for optimal uptime of the machine at a minimum cost.
  • Flexible, modular construction.
Brochure UniWinder

Description

Winder for carpet or technical yarns.

  • Very effective automatic doffing in 15 sec.
  • Accurate length measurement.
  • Easy to maintain thanks to accessibility of all parts.
  • Plc controlled with an excellent operator & maintenance interface.
  • Modular design with three Independent spindles per section.

Technical specifications

Material Filament or spun yarns – Synthetic or natural fibres
Yarn count 600 to 20.000 dTex
Layout   800 or 1000 mm
Number of positions 3 to 24 per machine
Speed up to 1000 m/min.
